Mitigation of Voltage Sags using Ultra capacitor based Dynamic Voltage Restorer Using PI Control Scheme

Swati Rambhad; S.R. Deore

Mitigation of Voltage Sags using Ultra capacitor based Dynamic Voltage Restorer Using PI Control Scheme

Authors: Swati Rambhad, S.R. Deore

Unique Paper ID: 146595
Volume: 5
Issue: 1
PageNo: 170-174

Keywords: Ultra-Capacitor (UCAP) DC-DC Converter Sag/Swell PI Controller energy storage integration phase locked loop (PLL).

Abstract:
The most severe power quality problems in electrical systems are called as voltage sag and swell. These power quality problems must be compensated accurately. There are two voltage injection strategies to inject controlled voltage via dynamic voltage restorer (DVR) in electrical systems Power Quality (PQ) is that the most vital views at transmission and distribution levels. The availability of high-grade electrical services needed to the purchasers illustrates this idea. The voltage sag and swell square measure the foremost frequent PQ issues that mainly occur within the distribution systems since it's going to cause equipment tripping, failure of drive systems, closure for domestic and industrial instrumentality. The Dynamic Voltage Restorer (DVR) connected nonparallel has splendid dynamic capabilities and is a versatile answer for PQ issues. Ultra-capacitors (UCAP) have ideal characteristics like high power and low energy density essential for the mitigation of voltage sag and swell. This paper presents AN increased DVR topology capable of delivering deep, extended mitigation for power quality issues. Within the planned DVR, UCAP is employed as energy storage because it provides excessive power in an exceedingly short interval of your time. The DVR is integrated into Ultra capacitor via bifacial DC-DC converter which supports in presenting a rigid dc-link voltage, and conjointly helps in compensating temporary voltage sag and voltage swell. PI Controller is employed in DVR for power quality improvement. The simulation model for the proposed system has been developed in MATLAB and therefore the performance over standard DVR is valid with the results obtained.

email to a friend

Cite This Article

ISSN: 2349-6002
Volume: 5
Issue: 1
PageNo: 170-174

Mitigation of Voltage Sags using Ultra capacitor based Dynamic Voltage Restorer Using PI Control Scheme

Available:https://ijirt.org/Article?manuscript=146595
